| Gehäuseausführung | 1/8" Barbs |
| Pneumatischer Luftanschluss | Square Body(Manifold and Barb) |
| Körper/Elastomer Werkstoff | Brass/FKM |
| Maximaler Betriebsdruck/Blendengröße | 150 psid/.010" |
| Maximale Betriebsspannung | 5.5 VDC |
| Elektrischer Anschluss | 18" Wire Leads |
| Durchfluss | Up to 5.5 SLPM |
| Maximaler Durchfluss | 5.5 SLPM |
| Unterdruck zu Druck-Bereich | 0-27 in Hg (0-686 mm Hg) |
| Funktion | 2-Way, Normally Closed (NC) |
| Zyklen pro Lebensdauer | 100 Million |
| Betätigungsart | Solenoid |
| Bedienungsart | Electronic |
| Regelungsmethode | Current or Voltage |
| Stromverbrauch | 2.0 W |
| Eingangsspannung | 5.5 VDC |
| Elektrischer Anschluss | 18" Wire Leads |
| Gehäusematerial | 360 H02 Brass |
| Dichtungsmaterial | FKM |
| Temperaturkompensation | Thermally Compensated |
| Leckagerate | < 0.016 sccm of Helium @ 150 psi |
| Montageart | Mounting screw |
| Anschlusstyp | Barbed port connections |
| Anschlussgröße | 1/8" barbs for I.D. Tubing |
| Für Fluidtyp | Gases |
| Industrieanwendung | Ventilators, Insufflators, Anesthesia Delivery & Monitors, Pressure & Flow Control and Mass Flow Control |
| Konfiguration | N/A |
