| Rohraußendurchmesser (mm) | 12.0 |
| Rohrinnendurchmesser | 10.0 |
| Länge (m) | 100.0 |
| Farbe | Schwarz |
| Rohrmaterial | PA |
| Maximale Betriebstemperatur | 80.0 °C |
| Medien | Hot and cold water, refrigerated fluids, compressed air |
| Gewicht | 7.0 kg/package |
| Anzahl Rohre | 1.0 |
| Maximaler Betriebsdruck | 36.0 barg |
| Erfüllte Spezifikationen | Industrial: DI: 2002/95/EC (RoHS), 2011/65/EC, DI: 97/23/EC (PED), RG: 1907/2006 (REACH), UL94 V-0 (Fire resistance) |
| Minimale Betriebstemperatur | -20.0 °C |
| Biegeradius | 90.0 mm |
