| Anschluss 2 Typ | Female JIC 37° - Swivel |
| Form | Gerade |
| Anschlussgröße | 1 1/2" |
| Schlauch-Innendurchmesser | -24 |
| Für Fluidtyp | Petroleum base hydraulic fluids and lubricating oils |
| Marke | Parker |
| Division | Polymer Hose Division Europe |
| Form | Straight |
| Anschlusstyp | DKJ |
| Erfüllte Spezifikationen | ISO12151-5-SWS |
| Anwendungen | Petroleum base hydraulic fluids and lubricating oils |
| Technologie | Fluid & Gas Handling |
| Produkttyp | Crimp Fittings – No-Skive |
| Größe Anschluss 2 | 1 7/8x12 |
| Connection Length | 69 mm (see drawing Legend B) |
| Fitting Length | 136 mm (see drawing Legend A) |
| Sechskantgröße 1 | 60 mm (see drawing Legend W) |
| Sechskantgröße 2 | 50 mm (see drawing Legend H) |
| Konfiguration | Hose to Port |
| Anschluss 1 Typ | Hose |
| Gehäusematerial | Steel |
